Подшипники шариковые радиально-упорные сдвоенные, наружные кольца обращены друг к другу широкими торцами, угол контакта α=36º
| Обозначение | Размеры | Масса (кг) | ||||
|---|---|---|---|---|---|---|
| По ГОСТу | Международное | d | D | B | r | |
| 266134 | - | 170 | 260 | 84 | 3.5 | - |
| 266136 | - | 180 | 280 | 92 | 3.5 | - |
| 266138 | - | 190 | 290 | 92 | 3.5 | - |
| 266140 | - | 200 | 310 | 102 | 3.5 | - |
| 266144 | - | 220 | 340 | 112 | 4 | - |
| 266148 | - | 240 | 360 | 112 | 4 | - |
| 266152 | - | 260 | 400 | 130 | 5 | - |
| 266156 | - | 280 | 420 | 130 | 5 | - |
| 266201 | - | 12 | 32 | 20 | 1 | 0.08 |
| 266202 | - | 15 | 35 | 22 | 1 | 0.1 |
| 266203 | - | 17 | 40 | 24 | 1 | 0.14 |
| 266204 | - | 20 | 47 | 28 | 1.5 | 0.22 |
| 266205 | - | 25 | 52 | 30 | 1.5 | 0.27 |
| 266206 | - | 30 | 62 | 32 | 1.5 | 0.4 |
| 266207 | - | 35 | 72 | 34 | 2 | 0.56 |
| 266208 | - | 40 | 80 | 36 | 2 | 0.74 |
| 266209 | - | 45 | 85 | 38 | 2 | 0.85 |
| 266210 | - | 50 | 90 | 40 | 2 | 0.96 |
| 266211 | - | 55 | 100 | 42 | 2.5 | 1.26 |
| 266212 | - | 60 | 110 | 44 | 2.5 | 1.6 |
| 266213 | - | 65 | 120 | 46 | 2.5 | 2 |
| 266214 | - | 70 | 125 | 48 | 2.5 | 2.2 |
| 266215 | - | 75 | 130 | 50 | 2.5 | 2.95 |
| 266216 | - | 80 | 140 | 52 | 3 | 3.68 |
| 266217 | - | 85 | 150 | 56 | 3 | 4.42 |
| 266218 | - | 90 | 160 | 60 | 3 | 4.52 |
| 266219 | - | 95 | 170 | 64 | 3.5 | 5.26 |
| 266220 | - | 100 | 180 | 68 | 3.5 | 6.64 |
| 266222 | - | 110 | 200 | 76 | 3.5 | 9.24 |
| 266224 | - | 120 | 215 | 80 | 3.5 | 10.96 |
| 266226 | - | 130 | 230 | 80 | 4 | 12.4 |
| 266256 | - | 280 | 500 | 160 | 6 | - |
| 266305 | - | 25 | 62 | 34 | 2 | 0.508 |
| 266306 | - | 30 | 72 | 38 | 2 | 0.766 |
| 266307 | - | 35 | 80 | 42 | 2.5 | 1.014 |
| 266308 | - | 40 | 90 | 46 | 2.5 | 1.39 |
| 266309 | - | 45 | 100 | 50 | 2.5 | 1.854 |
| 266310 | - | 50 | 110 | 54 | 3 | 2.4 |
| 266311 | - | 55 | 120 | 58 | 3 | 3.1 |
| 266312 | - | 60 | 130 | 62 | 3.5 | 3.88 |
| 266313 | - | 65 | 140 | 66 | 3.5 | 4.76 |
| 266314 | - | 70 | 150 | 70 | 3.5 | 5.78 |
| 266315 | - | 75 | 160 | 74 | 3.5 | 6.94 |
| 266316 | - | 80 | 170 | 78 | 3.5 | 8.24 |
| 266317 | - | 85 | 180 | 82 | 4 | 9.68 |
| 266318 | - | 90 | 190 | 86 | 4 | 11.3 |
| 266319 | - | 95 | 200 | 90 | 4 | 12.5 |
| 266320 | - | 100 | 215 | 94 | 4 | 16.08 |
| 266322 | - | 110 | 240 | 100 | 4 | 21.6 |
| 266324 | - | 120 | 260 | 110 | 4 | 27.4 |
| 266326 | - | 130 | 280 | 116 | 5 | 33.6 |
| 266328 | - | 140 | 300 | 124 | 5 | 40.8 |
| 266330 | - | 150 | 320 | 130 | 5 | 48.8 |
| 266336 | - | 180 | 380 | 150 | 5 | - |
| 266340 | - | 200 | 420 | 160 | 6 | - |
| 266405 | - | 25 | 80 | 42 | 2.5 | 1 |
| 266406 | - | 30 | 90 | 46 | 2.5 | 1.54 |
| 266407 | - | 35 | 100 | 50 | 2.5 | 2.1 |
| 266408 | - | 40 | 110 | 54 | 3 | 2.74 |
| 266409 | - | 45 | 120 | 58 | 3 | 3.5 |
| 266410 | - | 50 | 130 | 62 | 3.5 | 4.34 |
| 266411 | - | 55 | 140 | 66 | 3.5 | 4.6 |
| 266412 | - | 60 | 150 | 70 | 3.5 | 6.72 |
| 266413 | - | 65 | 160 | 74 | 3.5 | 6.8 |
| 266414 | - | 70 | 180 | 84 | 4 | 11.5 |
| 266415 | - | 75 | 190 | 90 | 4 | 11.8 |
| 266416 | - | 80 | 200 | 96 | 4 | 14.5 |
| 266417 | - | 85 | 210 | 104 | 5 | 16 |
| 266418 | - | 90 | 225 | 108 | 5 | 24 |
| 266420 | - | 100 | 250 | 116 | 5 | - |
| 266432 | - | 160 | 400 | 176 | 6 | - |
